JIESHENG
| Quantity: | |
|---|---|
Customized Capacity Fast Cooling Walk in Industrial Cold Room
| Capacity(M3) | Temperature Range | External Dimension (L*W*H)(m) | Double-side color steel PU panels (mm) | Swing Door | Copeland Air Cooling system | Evaporaotor | Power supply | Input Power |
| ≤15 m³ | 0-4 °C | Optional | 100mm | 700*1700mm | Air Cooling-1.5PH | DD-12 | 220V/50Hz | 1.1kw |
| 16-20 m³ | 1.1kw | |||||||
| 21-25 m³ | Air Cooling-2.0PH | DD-15 | 1.6kw | |||||
| 26-30 m³ | 800*1800mm | 1.6kw | ||||||
| 31-35 m³ | Air cooling-3PH | DD-22 | 220V/380V | 2.2kw | ||||
| 36-40 m³ | 380V | 2.2kw | ||||||
| ≥40 m³ | 4PH/5PH | DD-30/DD-40 | 380V | ≥3.0kw |
| Capacity(M3) | Temperature Range | External Dimension (L*W*H)(m) | Double-side color steel PU panels(mm) | Swing Door | Copeland Air Cooling system | Evaporaotor | Power supply | Input Power |
| ≤15 m³ | -18 °C | Optional | 120mm | 700*1700mm | Air Cooling -3PH | DD-22 | 220V/380V | 2.2kw |
| 16-20 m³ | 2.2kw | |||||||
| 21-25 m³ | Air Cooling -4PH | DD-30 | 3kw | |||||
| 26-30 m³ | 800*1800mm | 380V | 3kw | |||||
| 31-35 m³ | Air Cooling -5PH | DD-40 | 3.8kw | |||||
| 36-40 m³ | Air Cooling -6PH | 4.2kw | ||||||
| ≥40 m³ | Air Cooling -8PH | DD-60 | 6kw |
Customized Capacity Fast Cooling Walk in Industrial Cold Room
| Capacity(M3) | Temperature Range | External Dimension (L*W*H)(m) | Double-side color steel PU panels (mm) | Swing Door | Copeland Air Cooling system | Evaporaotor | Power supply | Input Power |
| ≤15 m³ | 0-4 °C | Optional | 100mm | 700*1700mm | Air Cooling-1.5PH | DD-12 | 220V/50Hz | 1.1kw |
| 16-20 m³ | 1.1kw | |||||||
| 21-25 m³ | Air Cooling-2.0PH | DD-15 | 1.6kw | |||||
| 26-30 m³ | 800*1800mm | 1.6kw | ||||||
| 31-35 m³ | Air cooling-3PH | DD-22 | 220V/380V | 2.2kw | ||||
| 36-40 m³ | 380V | 2.2kw | ||||||
| ≥40 m³ | 4PH/5PH | DD-30/DD-40 | 380V | ≥3.0kw |
| Capacity(M3) | Temperature Range | External Dimension (L*W*H)(m) | Double-side color steel PU panels(mm) | Swing Door | Copeland Air Cooling system | Evaporaotor | Power supply | Input Power |
| ≤15 m³ | -18 °C | Optional | 120mm | 700*1700mm | Air Cooling -3PH | DD-22 | 220V/380V | 2.2kw |
| 16-20 m³ | 2.2kw | |||||||
| 21-25 m³ | Air Cooling -4PH | DD-30 | 3kw | |||||
| 26-30 m³ | 800*1800mm | 380V | 3kw | |||||
| 31-35 m³ | Air Cooling -5PH | DD-40 | 3.8kw | |||||
| 36-40 m³ | Air Cooling -6PH | 4.2kw | ||||||
| ≥40 m³ | Air Cooling -8PH | DD-60 | 6kw |
